Products >> Reverse_osmosis_RO_system seawater desalination system

Membrane desalination equipment is a process in which seawater enters the low-pressure side of the membrane through a semi-permeable spiral wound membrane under pressure, and excess salt and minerals in the water are blocked on the high-pressure side and removed with concentrated seawater to obtain fresh water.

Process flow
Sea water → lifting pump → flocculation sedimentation storage tank → raw water booster pump → quartz sand filter → activated carbon filter → primary security filter → precision filter → sea water desalination high pressure pump → sea water desalination reverse osmosis device product water tank → water supply pump

System Supply List
1. Reverse osmosis membrane: adopts American Hydra, Dow or GE seawater membrane

2. Membrane shell: FRP material

3. High pressure pump: Danfoss super duplex steel

4. Energy recovery device: Danfoss super duplex steel or ERI

5. Frame: carbon steel spray paint epoxy zinc-rich primer, intermediate paint, polyurethane top paint 250μm

6. Piping: the high-pressure side pipeline adopts duplex steel or stainless steel pipeline and high-pressure hose, and the low-pressure side pipeline adopts UPVC pipeline

7. Electrical appliances: Siemens or ABB PLC, original electrical appliances Schneider

Features
1. The reverse osmosis seawater desalination technology is mature and advanced, with a high degree of automation, which can realize the automatic operation of the whole machine;

2. Energy consumption is reduced. The desalination of seawater with energy recovery consumes about 4.5 kWh of electricity per ton of water, which saves energy and reduces the cost of water production;

3. The combination types of reverse osmosis desalination equipment can be realized: bracket type, skid type, skid type, container type, etc.

Application:
Marine engineering, electric power, petrochemical, processing companies, public energy units, petroleum refineries, chemical companies, municipalities and defense agencies.
